Alupanel A-Lite Digital

Die flache, glatte Oberfläche mit deutlich verbesserter Farbhaftung macht Farbdrucke noch strahlender und intensiver.

Warum Alupanel A-Lite?

  • Manufactured in the UK
  • Has a 100% Recycled LDPE core and can be fully recycled after use
  • Meets fire test EN 13501 to class C-s2,d0 (2mm - 6mm) / NF P 92-507 Class M1 (3mm)
  • Specially developed brighter Signal White finish
  • Benefits from a thicker 0.22mm print surface
  • High quality 5005 alloy
  • enhanced Matt/Matt digital surface
  • Rigid, lightweight panel
  • Flat, smooth, uniform surface
  • Clean, easy-peel film, reducing cleaning, labour and production turn around
  • Premium quality print product
  • 2-year warranty
KlebstoffCoextrudiert für hohe HaftungKernHochwertiger LDPE-Kern 100% RecycledAluminiumschicht0,22 mm dickes, hochwertiges Aluminiummit hervorragender Flachheit undSteifigkeitLackierungBeide Seiten unserer A-Lite-Platteverfügen über eine strahlendere,konsistentere Signalweiß, matteLackierung nach Maß. Sie wurdespezielle für den Digital- undSiebdruck entwickelt, um leuchtende undintensive Farbdrucke mit hoherBeständigkeit zu ermöglichen.SchutzfolieZum Schutz der Platte bei Lagerung,Transport und Einbau verfügt A-Liteüber eine hochwertige EasyPeel-Schutzfolie, die sauber und leichtablösbar ist und keine Rückstände aufder Platte hinterlässt.

Multipanel is a competent and reliable partner for us. The service internal as well as external is excellent and the agreements and delivery dates are respected. The product quality is on a high level and comparable with the competitive products on the market at any time. The newly added coatings and core choices for A-Lite that have recently been introduced, are a sensible addition to the already large product portfolio...

Customer from Germany
A Lite print new reduced

DETAILS

Elevate your work with Alupanel A-Lite Digital, our premium-tier composite panel engineered for those who refuse to compromise on quality. While standard panels get the job done, A-Lite Digital is meticulously crafted with high-grade 5005-series alloy with a 0.22mm surface to provide an ultra-flat, rigid canvas that thrives under the pressure of high-speed production.

The difference is in the finish: our specialized Signal White digital coating offers unrivaled ink adhesion, transforming every design into a masterpiece of increased brightness, vivid color intensity, and long-term durability. When your reputation relies on the sharpest, most vibrant prints in the industry, this is the superior surface your business deserves.

Alupanel A-Lite Digital is also available with higher fire rated M1 class core.

Brighter, More Intense Colours:

- Experience significantly enhanced ink adhesion on our optimized coating print surface, resulting in richer, more vibrant, and attention-grabbing graphics.

Exceptional Print Clarity:

- The ultra-smooth, uniform Signal White matt polyester paint surface provides the ideal foundation for high-resolution digital and screen printing, ensuring crisp and detailed results at high speed

Unmatched Durability & Flatness:

- Benefit from a rigid and impact-resistant panel featuring thicker 0.22mm faces with a 5005 series alloy base. This not only provides superior stability and exceptional flatness, crucial for protecting your print hardware, but also offers enhanced erosion resistance for longer-lasting outdoor applications due to the alloy's magnesium content.

Effortless Routing & Fabrication:

- The combination of our 100% recycled LDPE core and the 5005 series alloy which offers excellent machinability, make routing and fabrication cleaner and easier, saving you time and tooling costs.

Faster, Cleaner Production:

- Our improved low-tack protective liner releases effortlessly, saving you time and preventing ghosting and print lines, contributing to a smoother production process.

Environmentally Conscious Choice:

- Manufactured in the UK with a 100% recycled LDPE core, supporting sustainable practices as we are not only within the same continent as the majority of our main customers but also offer recycling options for used panels post project completion (currently available for PE cores in the UK only).

Versatile Applications:

- Perfect for a wide array of flat applications, including direct UV & screen printing, sign making, wayfinding, POS/POP displays, vinyl application, and more.

Guaranteed Quality:

- Enjoy peace of mind with our 2-year warranty, a testament to the product's superior durability and performance.

Optimized for Efficiency:

- Available in a comprehensive range of formats, thicknesses (2mm to 6mm), widths (1000mm to 2050mm), and lengths (2440mm to 6000mm) to maximize material yield and minimize waste.

>> VIDEO - PRINTING ON A-LITE


Weitere Informationen können den unten stehenden Produktbroschüren und Datenblättern entnommen werden.

BROSCHÜREN ANSEHEN
2017 05 09 13 45 21

ANWENDUNGEN

Alupanel A-Lite ist für eine Reihe verschiedener flacher Anwendungen geeignet, insbesondere dort, wo hochwertige, strahlende Farbdrucke gewünscht sind.

  • Beschilderung
  • Wegeführung
  • 3D-Buchstaben
  • Erhabene Buchstaben
  • Leichte Hängeschilder
  • POS-Displays
  • Vinyl-Anwendungen
  • Modulare Schildersysteme
  • Bauzäune
  • Messestand-Design
  • Außenwerbung
  • Innenverkleidung und -gestaltung
  • UV- und Sieb-Direktdruck
  • Transport
  • Spritzschutz
Tumi Store Beverly Centre Usa 2 1000X1000
04 News Print Week Hoarding 1Bd784A51D 1000X1000
Alupanel A Lite Print Max
Alupanel Spiderman Roland LEF 200
Sign Display Best Buy Gaming
Sign Display Best Buy Ue

TECHNISCHE DATEN

Die folgenden Tabellen enthalten Angaben über die verfügbaren Plattengrößen und -dicken sowie technische Daten von Alupanel A-Lite.

Plattendicke (mm)2346
Deckschicht (mm)0.220.220.220.22
Gewicht (kg/m2)2.63.64.56.3
1000mmx2015mm
1000mmx2440mm
1000mmx2050mm
1000mmx3050mm
1220mmx2440mm
1220mmx3050mm
1250mmx2550mm
1250mmx3050mm
1500mmx3050mm
1500mmx4050mm
1525mmx3050mm
1560mmx3050mm
2000mmx3050mm
2000mmx4050mm
2050mmx3050mm
2050mmx4050mm
Plattendicke (mm)2-6mm
Schallabsorption
Schalldämmung
Wasserabsorption0.01
Kühlleistung (Wärmewiderstand)
Kernzusammensetzung100% Recycled LDPE
BrandverhaltenEN 13501 to class C-s2,d0 (2mm - 6mm) / NF P 92-507 Class M1 (3mm)
Zugfestigkeit der Aluminiumschichten160MPa
Plattendicke (mm)-0 + 0.2
Breiten (mm)-0 +2
Längen (mm)-0 +3
Diagonale-0 +5
Wärmeausdehnung2,4 mm/m bei 100ºC Temperaturunterschied
AluminiumdickeWie in EN 485-4 angegeben
Lackdicke (microns)
Bleistifthärte2H
Härte der Beschichtung3T
Temperaturbeständigkeit-50ºC to +80ºC
Schlagfestigkeit (kg/CM2)
Siedewasserbeständigkeit2 Stunden Sieden ohne Veränderung
SäurebeständigkeitOberfläche eingetaucht in 2% HCl für 24 Stunden ohne Veränderung
AlkalibeständigkeitOberfläche eingetaucht in NaOH für 24
ÖlbeständigkeitOberfläche eingetaucht in 20# Motoröl für 24 Stunden ohne Veränderung
Lösungsmittelbeständigkeit100-mal mit Dimethylbenzol gereinigt ohne Veränderung
Reinigungsfestigkeit>1000-mal ohne Veränderung
Schälfestigkeit>5 Newton/mm
